GM-650-5AXIS CNC Five axis Machining Center 'High Speed’
With flexible 5 axis cnc machining center, you can meet the challenges of a variety of applications and short-term market requirements, processing from blank to finished parts in a minimal footprint, and producing parts in a single clamping operation on the same machine tool.
Classification:
Key words:
CNC Vertical Machining Center
cnc 5 axis vertical machining center
5 axis cnc machining center
5 axis cnc machine
Detail description
GM-650-5AXIS Five axis high speed CNC Vertical Machining Center is mainly used for high precision parts processing, trial production; Processing plan, process optimization, etc.
With flexible 5 axis cnc machining center, you can meet the challenges of a variety of applications and short-term market requirements, processing from blank to finished parts in a minimal footprint, and producing parts in a single clamping operation on the same machine tool.
All-weather flexible production, help you to respond to the temporary requirements of customers at any time. From mass production to fast operation in minutes.
The fastest 5 axis machining center precision solution, with optimized machine tool design to achieve automation, obtain reliable system for all weather 5 axis machining production.
1, mechanical structure simple design, with high speed, high precision, high stability of the spindle
2. High dynamic response direct drive technology workbench
3, standard brand five-axis control system
4. Efficient composite processing technology
5. Configure lubricating oil system to ensure good lubrication of all moving parts of the machine tool
6, cnc 5 axis vertical machining center can be optional chain-type chip discharge, automation, humanization, high efficiency
cnc 5 axis vertical machining center for sale：market001@glorymaq.com call me now！
| Technical specification | ||
| MODEL | GM-650-5A | |
| Axis travel | ||
| X-axis | mm | 820 |
| Y-axis | mm | 520 |
| Z-axis | mm | 500 |
| A/C axis travel | mm | ±110°/360° |
| Distance from spindle center line to column | mm | 150-650 |
| Maximum work piece | mm | Φ650 |
| Maximum workpiece weight | kg | 300kg |
| Spindle | ||
| Spindle speed | rpm | 12000 |
| Spindle power | kw | 11 |
| Spindle torque | N.m | 51/61 |
| Three-axis motor power | kw | 4.5/4.5/4.5 |
| Spindle connection mode | Direct drive | |
| X Y Z axis connection type | ||
| Linear guide(X/Y/Z) | 45/45/45 | |
| Feed | ||
| Rapid traverse (x/y/z) | m/min | 24/24/24 |
| Cutting feed rate | m/min | 10 |
| Accuracy | ||
| Repeated positioning accuracy (X/Y/Z) | mm | 0.005 |
| Positioning accuracy(X/Y/Z) | mm | 0.005 |
| Repeated positioning accuracy(A/C ) | arcsec | ±10″ |
| Positioning accuracy(A/C ) | arcsec | ±5″ |
| Optional * | ||
| System | SYNTEC 22MA / SIEMENS-828D | |
| Other | ||
| Tool number | pcs | 24 |
| Maximum tool weight | kg | 16 |
| Maximum tool length | mm | 250 |
| Maximum tool diameter | mm | Φ200 |
| Evaluated machine weight including accessories | kg | 10500kg |
| Machine power | kw | 30 |
| Machine size | mm | 4900*3750*3500 |
Refer to Power Requirements
| Power correspondence table |
55～90A |
220V |
60Hz |
3Φ |
25kW |
Refer to Pressure Requirements
| Pressure source pressure | Set pressure | Ambient temperature | Relative humidity | Air supply |
|
5～7bar |
5bar |
0～45℃ |
＜90%RH |
380l/min |
